36 pulses output transformer for variable frequency converter

2025-03-18

Dry type phase shift rectifer transformer is a specialized multi-winding transformer designed to introduce precise phase shifts between the primary and secondary windings. Varelen design and manufactured 18 pulse shift phase transformer, dry type shift phase transformer used as supply transformer of Test room for Medium Voltage IGBT Vafiable Frequency Converter .

The equipment suppliers multi-phase power to mid&high volt conveters,which is commonly applied to boiled fan, water supply systems, metallurgy, chemical industry and automatical municipal facilities.



dry type phase shift tansformer

Environmental   Conditions



Key Advantages of Multi-Winding Phase Shift Transformers

Dry-type rectifier duty phase-shifting transformers offer a range of performance benefits that make them ideal for heavy-duty industrial applications:



1. Improved Power Quality & Grid Impact

  • Enhances voltage stability and reduces reactive power issues
  • Prevents overloading of feeders, circuit breakers, and transformers
  • Supports efficient grid interaction and power flow

2. Enhanced Equipment Protection

  • Enables smooth motor starts, reducing mechanical and electrical stress
  • Extends the service life of motors, drives, and transformers
  • Minimizes downtime and maintenance costs

3. Compact and Robust Design

  • Electromagnetic and structural optimization reduces overall size and noise levels
  • Strong coil support structures ensure high short-circuit resistance
  • Designed for long-distance transport and harsh operating conditions without maintenance

4. High Energy Efficiency & Sustainability

  • Constructed with low-loss, high-performance silicon steel cores
  • Low magnetic flux density design prevents core saturation under harmonic stress
  • Windings engineered with low current density for better thermal performance and longevity

5. Customization design

Multi-winding design with phase shifted secondary windings.  Multiple winding rectifiter transormer have different phase available, 6, 12, 18,24, 36 pulse.

6. Advanced Insulation and Durability

  • Vacuum Pressure Impregnation (VPI) insulation enhances thermal endurance
  • High mechanical strength ensures reliable operation during short-circuit events
  • Maintenance-free design ideal for remote or demanding environments



Why Choose Varelen Dry-Type Phase Shift Transformers?

Excellent structure, small size and high reliability:
1. With electromagnetic and structural optimization design, small size and lower noise;
2. Same mold windings, special support structure for coil end surface, high strength mechanical, high ability of withstand short-circuit, safe and reliable;
3. Maintenance-free fastening body structure, keep reliable in the long-distance transport and operation
4.Lead lays out neatly, reasonable and nice.


Good solution to harmonic influence:
1. Made of high-performance silicon steel sheet material and lower magnetic flux density design so as to withstand over-voltage and harmonic influence unsaturated.
2. Lower current density design and sufficient margin to make winding withstand additional temperature rise caused by harmonic.
3. Advanced insulation structure that can withstand a variety of over-load insulation impact.
4. Reaching up to maximum 27 phase for secondary winding in result a great reduction of the harmonics influence on the power grid and other equipment.



Applications of Multi-Winding Phase Shift Transformers

Phase shift transformers play a critical role in industries where power quality, system reliability, and motor protection are paramount.   applications include:

  • Power Generation Plants: Boiler fans, feedwater pumps, and other large motor systems
  • Petrochemical and Chemical Industries: Refineries, gas plants, and production facilities
  • Municipal Infrastructure: Water supply systems, wastewater treatment, and pumping stations
  • Metallurgical & Steel Mills: Rolling mills, furnaces, and process control systems
  • Cement and Mining: Crushers, mills, and heavy conveyors
  • Pulp and Paper Industries: Automation lines and large process motors
  • Pharmaceutical Manufacturing: Precision production requiring clean, stable power



Future Outlook: Rising Demand for High-Pulse Transformer Solutions

With industries rapidly moving toward digitalization and smart manufacturing, the need for clean, reliable power is greater than ever. Emerging trends driving the demand for high-pulse phase shift transformers include:

  • Tighter grid codes pushing for better harmonic control
  • Greater integration of renewable energy sources requiring advanced rectification
  • Increasing need for smart grid compatibility and real-time power management
  • Continuous design improvements for reduced size, weight, and environmental impact

Investing in high-pulse transformers positions industrial operations to meet these future demands while securing stable and efficient power delivery.



Conclusion: Varelen’s Phase Shift Transformers—Engineered for Performance and Reliability



By choosing Varelen’s 18-pulse dry-type phase shift transformers, you gain:

  • Cleaner, more reliable power
  • Superior harmonic mitigation
  • Enhanced equipment protection
  • Long-term operational savings

Varelen is the trusted partner for industries seeking robust, high-performance power solutions. Our transformers are the ideal choice for power plants, water facilities, heavy industries, and modern manufacturing environments where harmonic control and efficiency are mission-critical.
